SPECIFICATION:

Item No : ML-CB49

Equipped with i7 CPU 120G solid state drive, 8G running memory
Quart machine installation 17.1 and 18.0 versions system
Ultra-compact shape is only 42.5cm wide
3 metal precision photoelectric encoders
10 groups of assignable playback faders
(Connected to the Titan Mobile Wing Titan Mobile Wing can be expanded to add 20 sets of playback faders)
20 custom function buttons (video work window “Workspaces” / macro “Macros” / execute “playback”)
(Connected to the Titan Mobile Wing Titan mobile wing expandable to add 30 custom function buttons)
2048 channels 4 independent DMX512 outputs, plus an Ethernet extender to increase output channels to 8192
(Extensible to 32768 output channels via Titan Net Processor)
Built-in UPS can run for 1 hour in case of power failure
Equipped with 14.1” precision touch screen
The system supports dual display
Panel mounted super high speed USB 3.0 interface, Gigabit network port
MIDI input control lighting effects and trigger time code automatic replay performance program
Compatible with smart mobile phones Android and Apple system remote control operations
Support multi-band sound trigger (sound-to-light)
Uniform button layout with other Titan series consoles
1000 virtual trigger playback buttons
Provide multi-language operation interface
Leading Titan operating system
Strong field running sequence control
Built-in lighting simulator and light library writing software
Multiple working windows provide easy operation and configuration of fixture data
Performance files are common to all Titan system consoles
With video media material thumbnail preview and operating system
Unique “Quicketch” hand-drawn tool for quickly creating custom graphic annotations
Network tracking backup, multi-user system
Light matrix pixel image programming function
Configurable group brightness, speed and time fader use
Compatible with other TITAN system console performance files

Console size:425*466*194mm
Net weight: 8KG
Package size: 53*32*59CM

G.W:23KG
