DMX 12 Switch Box
Product Overview
Item No : ML-C19
Dimension: 480mm×146mm×74mm
Carton size:510mm × 185mm × 140mm
Net Weight: 2.2kg
G.W: 2.8 kg
- Intorduction
- Video Show
SPECIFICATION:
●Item No : ML-C19
●DMX512/1990 Standard
●12 channels switch output with Tric
●Switch output feature: DMX channel value 0-126=OFF, 127-255=ON
●Silicon bidirectional thyristors and zero-crossing triggering
●LED indicators for each channel
●Over current protected with rapid fuse
●Channel output: 5A per channel, 16A total
●There are nine internal chase program and the speed of these chase program can be selected
●DMX input connector: XLR-D3M
●DMX output connector: XLR-D3F
●Power supply: AC 100-240V 50/60Hz
●Dimension: 480mm×146mm×74mm
●Net Weight: 2.2kg
●Item No : ML-C19
●DMX512/1990 Standard
●12 channels switch output with Tric
●Switch output feature: DMX channel value 0-126=OFF, 127-255=ON
●Silicon bidirectional thyristors and zero-crossing triggering
●LED indicators for each channel
●Over current protected with rapid fuse
●Channel output: 5A per channel, 16A total
●There are nine internal chase program and the speed of these chase program can be selected
●DMX input connector: XLR-D3M
●DMX output connector: XLR-D3F
●Power supply: AC 100-240V 50/60Hz
●Dimension: 480mm×146mm×74mm
●Net Weight: 2.2kg
