P6 full color video display screen
Product Overview
Item No : ML-DS12Product Name：P6 full color video display screen
- Intorduction
- Video Show
SPECIFICATION:
Item No : ML-DS12
Product Name：P6 full color video display screen
Pixel Pitch 6mm
LED per pixel 1R1G1B (SMD 3 in 1)
Module Size: 192*96mm
Cabinet Dimension(W x H) 768*576mm
Cabinet Material Steel made (aluminium optional)
Best View Distancing 3-38m
Vertical Viewing Angle 1200
Horizontal Viewing Angle 1500
Brightness ≥2000CD/m2
Brightness Adjustment 100 grades by control software
Grey Scale 4096 level for each color
Operating Temperature -20℃-- +60℃
LEDs Lifetime ≥100000 hours
Input Voltage AC 220V/110V
Input Power Frequency 60HZ/50HZ
Screen Power Consumption Max 1200W/m2 ，Average 500W/m2
Refresh Rate ≥180HZ
Frame Rate 60HZ
Defect Rate ＜0.0001
Data Transfer Method Internet Wire/optical fiber
Humidity 10% --- 95%
Control Method Synchronous System
Way of Drive Constant, 1/8 scan
MTBF ≥5000 hours
Ingress Protection IP31
Color Temperature 5000—9300 K(adjustable)
Support Mode 640 x 480/800 x 600/1024 x 768
Control Distance Internet Wire : 120 m ; Optical fiber : 10000 m
Systems Operating Platform Windows 98 /2000/NT/XP/2003
Item No : ML-DS12
Product Name：P6 full color video display screen
Pixel Pitch 6mm
LED per pixel 1R1G1B (SMD 3 in 1)
Module Size: 192*96mm
Cabinet Dimension(W x H) 768*576mm
Cabinet Material Steel made (aluminium optional)
Best View Distancing 3-38m
Vertical Viewing Angle 1200
Horizontal Viewing Angle 1500
Brightness ≥2000CD/m2
Brightness Adjustment 100 grades by control software
Grey Scale 4096 level for each color
Operating Temperature -20℃-- +60℃
LEDs Lifetime ≥100000 hours
Input Voltage AC 220V/110V
Input Power Frequency 60HZ/50HZ
Screen Power Consumption Max 1200W/m2 ，Average 500W/m2
Refresh Rate ≥180HZ
Frame Rate 60HZ
Defect Rate ＜0.0001
Data Transfer Method Internet Wire/optical fiber
Humidity 10% --- 95%
Control Method Synchronous System
Way of Drive Constant, 1/8 scan
MTBF ≥5000 hours
Ingress Protection IP31
Color Temperature 5000—9300 K(adjustable)
Support Mode 640 x 480/800 x 600/1024 x 768
Control Distance Internet Wire : 120 m ; Optical fiber : 10000 m
Systems Operating Platform Windows 98 /2000/NT/XP/2003
