P6 Outdoor LED Video Display Screen
Product Overview
Item No : ML-DS04ProductName：P6 full color display screen
- Intorduction
- Video Show
SPECIFICATION:
Item No : ML-DS04
ProductName：P6 full color display screen
Pixel Pitch：6mm
Pixel Configuration ：1R1G1B
Pixel LED：SMD3535
Module Size(W * H)：192mm *192mm
Resolution：32* 32
Driving Mode：Constant Current
Scanning Mode ：1/8
Power supply ：AC110/220±10% 50/60Hz
Power consumption (Average )：400 W/ 2
Power consumption (Maximum )：1200W/ 2
Switching Power Supply: Power 5V40A CHUANGLIAN
Brightness /Luminance : 5500--6000cd/square meter
Refreshing Frequency : 800--2000Hz
Square density: 27777
Horizontal Viewing Angle: H: ± 150 ° V: ± 120 °
Best viewing distance: 4 m - 40 m
Plane flatness: less than 1mm
Module gap: less than 1mm
Grayscale / color: RGB each 256 / 68.7 billion displayable colors
Detective change frequency: ≥60 surveillance seconds
Protection Grade : IP65
Anti-UA: 100% protection
Working environment: -20 ℃ ~ + 50 ℃
Storage environment: -20 ℃ ~ + 50 ℃
Display Screen Lifetime : 100,000 hours
Display Format : 1024 * 768
Item No : ML-DS04
ProductName：P6 full color display screen
Pixel Pitch：6mm
Pixel Configuration ：1R1G1B
Pixel LED：SMD3535
Module Size(W * H)：192mm *192mm
Resolution：32* 32
Driving Mode：Constant Current
Scanning Mode ：1/8
Power supply ：AC110/220±10% 50/60Hz
Power consumption (Average )：400 W/ 2
Power consumption (Maximum )：1200W/ 2
Switching Power Supply: Power 5V40A CHUANGLIAN
Brightness /Luminance : 5500--6000cd/square meter
Refreshing Frequency : 800--2000Hz
Square density: 27777
Horizontal Viewing Angle: H: ± 150 ° V: ± 120 °
Best viewing distance: 4 m - 40 m
Plane flatness: less than 1mm
Module gap: less than 1mm
Grayscale / color: RGB each 256 / 68.7 billion displayable colors
Detective change frequency: ≥60 surveillance seconds
Protection Grade : IP65
Anti-UA: 100% protection
Working environment: -20 ℃ ~ + 50 ℃
Storage environment: -20 ℃ ~ + 50 ℃
Display Screen Lifetime : 100,000 hours
Display Format : 1024 * 768
Respective Products Type Submit Time Size
